Galfan Welded Gabion Stone Wall For Landscape Stone Cage Retaining Wall

Brand Name : LJ

Model Number : LJ-12

Certification : ISO9001,SGS

Place of Origin : Hebei Province,China

MOQ : 50 Sets

Price : $8.5-10.9 per meter

Payment Terms : T/T

Supply Ability : 1000 sets per day

Delivery Time : 7-20days according to the quantity

Packaging Details : steel pallet

Production : Welded Gabion Mesh

Key Words : Stone Cage,Gabion Cage

Material : galvanized wire, pvc coated wire, galfan wire

Gabion Size : 1*1*0.5m, 1*1*1m, 2*1*1m, 4*1*1m

Aperture : 6x8cm, 8x10cm,10x12cm, 12x15cm

Surface treatment : hot dipped zinc Coated

Wire Diameter : 2.0mm-5.0mm

Usage : Flood Control Retaining Wall

Feature : Firm Structure, Durable, Beautiful, Easy Install

Port of Loading : Xingang Port,China

Origin : Hebei Province,China

Contact Now

Galfan Welded Gabion Mesh Stone Box Gabion Walls For Landscape Walls

Description of Gabion Mesh

Gabion mesh is a mesh structure mechanically woven from high-corrosion-resistant, high-strength, and ductile low-carbon steel wire or PVC-coated steel wire. When filled with stones, it forms a stable box-like structure.

Its core advantages lie in its ‌flexible structure‌, which can adapt to ground deformation without being easily damaged, offering excellent stability. It is also ‌permeable‌, effectively preventing water pressure buildup, reducing the risk of structural damage, and being beneficial for ecological protection. Additionally, it is ‌easy to construct‌, requiring no special equipment or techniques, which can significantly shorten construction time and reduce costs.

Specification of Gabion Mesh

Material	Galvanized Steel Wire, Galfan Steel Wire/Zinc-5%Aluminum Wire
Wire Diameter	2.2mm, 2.5mm, 2.7mm, 3.0mm, 4.0mm, 5.0mm etc
Aperture	5050 mm, 50100 mm, 75x75mm, 75x100mm, 100x100mm etc
Finish	Hot Dipped Galvanized; Heavy Zinc Coating;Galfan Coating;PVC Coated.
Normal Box Size(cm)	Diaphragms	Capacity (m3)	Mesh Size(mm)
100x30x30	None	0.09	50x50 mm 50x100 mm 75x75mm 75x100mm 100x100mm
100x50x30	None	0.15
100x100x50	None	0.5
100x100x100	None	1.0
150x100x100	1	1.5
200x100x50	1	1.0
200x100x100	1	2.0
300x100x50	2	1.5
300x100x100	2	3.0
400x100x50	3	2.0
400x100x100	3	4.0
Other sizes can be customized.

Features of Gabion Mesh

1.Blends easily and harmoniously with the natural surroundings.

2.Low cost

3.Good resistance to natural forces

4.Can withstand unpredictable movement or settlement without loss of stability

5.Permeable

6.Simple and fast installation

7.Quality finish and appearance

8.Quick and cheap to install

9.Easy to vegetate

Application of Gabion Mesh

Rockfall and soil erosion protection.
Coastal defence and protection works.
Landscaping.
River and canal training.
Boundary walls.
Architectural cladding for walls and buildings.

Gabion Mesh Package

1.With plastic weaving bags outside

2.With wooden pallet cloth

3.Less transport freight. It can be folded together for transport and further installation.
